34
Minimum value Maximum value
mm inch mm inch
A Label width 21.50 0.83 118.00 4.65
B Backing paper width 25.40 1.00 118.00 4.65
C Left edge position of label 0 0 2.54 0.10
D Label gap length 2.54 0.10 2,539.75 (CL-E321)
1,270.00 (CL-E331)
99.99 (CL-E321)
50.00 (CL-E331)
E Label length 6.35 0.25 2,539.75 (CL-E321)
1,270.00 (CL-E331)
99.99 (CL-E321)
50.00 (CL-E331)
F Label pitch 8.89 0.35 2,539.75 (CL-E321)
1,270.00 (CL-E331)
99.99 (CL-E321)
50.00 (CL-E331)
G Backing paper thickness 0.06 0.0025 0.125 0.0049
H Total media thickness 0.06 0.0025 0.19 0.0075
I Notch right edge position 8.3 0.32 60.80 2.39
J Notch left edge position 0 0 57.20 2.25
K Notch length 2.54 0.10 17.80 0.70
L Black line right edge
position
15.00 0.59 66.50 2.62
M Black line left edge
position
0 0 51.50 2.02
N Black line length 3.18 0.125 17.80 0.70
Use the transmissive sensor when using media that has both gaps between labels
and black lines.
Use the transmissive sensor when using fanfold media.
If the label pitch is 1 inch or less, congure an accurate label pitch with the [Small
Media Adjustment] setting.
Use carbon-based ink with an OD value of at least 1.5 to print black lines.
The stop position and cut position may change depending on the width or type of
media that is used.
Adjust these positions using the Paper Position setting.
