Citizen CL-E321 User Manual

27
——
3. SETUP
3.1 Printing Preparation Process
The printer must be set up according to the following process before printing can be
performed.
Refer to the description of each section for detailed information on each step of the
process.
1. Unpack and check the package contents
Refer to 1.2 Unpacking
2. Physical installation
3. Loading Media
Refer to 3.2 Loading Paper
4. Loading a Ribbon
Refer to 3.3 Loading a Ribbon
5. Adjusting Media Sensor Positions
Refer to 3.4 Adjusting Media Sensor Positions
6. Connecting the AC Adapter
Refer to 3.5 Connecting the AC Adapter
7. Connecting the Printer to a Host Computer
Refer to 3.6 Connecting the Printer to a Host Computer
8. Operation Check
Refer to 7.2 Test print mode
9. Installing the Printer Driver onto the Host Computer
Refer to 3.7 Install the Printer Driver
10. Installing the Conguration Application onto the Host Computer
Refer to 4.2 Obtaining the LabelPrinterUtility
11. Printing
Perform a test print from the printer driver installed on the host computer.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
