Citizen CL-E321 User Manual

66
——
6. Conguring Printer Settings Using a
Browser
Printer and network settings can be congured using a Web browser via the printer’s
built-in LinkServer function.
6.1 LinkServer user roles
LinkServer has the following three user roles available: User, Operator, and Administrator
The menus that appear for each user role can be changed to restrict operational ac-
cess to LinkServer.
The Home screen for the user role appears when rst connecting.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
