Citizen CL-E321 User Manual

63
——
5. Conguring Ethernet Network
Settings Using Network Seeker
You can check and change the settings of the wired LAN interface board by using
CITIZEN Network Seeker, which is utility software that runs in Windows.
5.1 Starting Network Seeker
After obtaining the program “NetSeeker.exe” from the CD-ROM or our website, double
click the program. A dialog box appears.
Start a search for printers by clicking the Seek button.
1
4
3
6
8
7
5
2
1. “Seek” button
Start a search for Ethernet interface boards on the network.
Waits for a response during the time congured with [Communication timeout].
2. “Edit cong” button
Change the settings of the selected board.
3. Board information list
Single click to select a board and double click to change settings.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
