Citizen CL-E321 User Manual

92
——
Reliability
Item Description
Head When the recommended paper is used under our given printing conditions:
Wear resistance 50 km (damage due to foreign matter being caught in the
head is not applicable)
Platen 100 km
Auto cutter Min. 300,000 cuts (60 μm ≤ paper thickness < 150 μm)
Min. 100,000 cuts (150 μm ≤ paper thickness ≤ 190 μm)
Environmental conditions
Refer to 11.3 Usage Conditions
Refer to 11.4 Storage Conditions
Electrostatic Voltage
EN61000-4-2:2009-compliant
AC Power Consumption
Item Description
CL-E321 100 V/50 Hz: 1.7 W standby,
70 W during operation
(Thermal-transfer, USB, print speed of 8 IPS, print density of 10, and printing rate of
12.5%)
220 V/50 Hz: 1.7 W standby,
66 W during operation
(Thermal-transfer, USB, print speed of 8 IPS, print density of 10, and printing rate of
12.5%)
CL-E331 100 V/50 Hz: 1.7 W standby,
66 W during operation
(Thermal-transfer, USB, print speed of 6 IPS, print density of 10, and printing rate of
12.5%)
220 V/50 Hz: 1.7 W standby,
63 W during operation
(Thermal-transfer, USB, print speed of 6 IPS, print density of 10, and printing rate of
12.5%)
External Dimensions
Refer to External Dimensions*5

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
