39
5.
Set the ribbon shaft with the loaded ribbon on the delivery side of the ribbon drive part.
Insert the right part of the ribbon shaft along the attachment guides and into the attachment
hole while pressing the left part of the ribbon shaft against the protruding part of the ange.
Protruding
part
Flange
on delivery side
Attachment hole in
left part of ribbon shaft
Ribbon shaft
attachment guides
on delivery side
Ribbon shaft
attachment hole
on delivery side
Protrusion of
right part of
ribbon shaft

Table of Contents

Other manuals for Citizen CL-E321

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Citizen CL-E321 and is the answer not in the manual?

Citizen CL-E321 Specifications

General IconGeneral
Print TechnologyThermal Transfer / Direct Thermal
Resolution203 dpi
Power Supply100-240V AC, 50/60 Hz
Max Print Width4.1 inches (104 mm)
Media SensorTransmissive and reflective sensor
InterfaceUSB, Serial (RS-232)
Media Width1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode TypesCode 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media TypesContinuous, Die-cut
Media Thickness0.0635 – 0.254 mm (2.5 - 10 mil)
Print SpeedUp to 8 inches per second
