Citizen CL-E321 User Manual

48
——
4. If there is slack on the right side, turn the ribbon left/right balance adjustment knob
toward the back.
Ribbon
Ribbon left/right balance
adjustment knob
The right side of the ribbon guide shaft will rise up in the opposite direction to the thermal
head.
Ribbon guide shaft
Ribbon
Once you have determined the adjustment position, tighten the screw.
Perform a test print in self-print mode and check that wrinkles do not occur.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
