Citizen CL-E321 User Manual

75
——
3. Press and hold the FEED key for at least 3 seconds.
4. Release the FEED key once the buzzer emits a long tone.
The printer is now in test print mode.
5. Press the FEED key to select the media.
Each press of the FEED key toggles between label media and continuous media.
Media Buzzer Status LED
Color Interval
Label media 1 short tones Green Flashes
Press the FEED key
↕
Continuous 2 short tones Green Flashes quickly
6. Press and hold the FEED key for at least 3 seconds.
7. Release the FEED key once the buzzer emits a long tone.
The test print process starts.
 Once the test sample has been printed, press the FEED key to print another test sample
without a feed operation.
8. Once the test sample has been printed, turn the power to the printer off and on again
to reset the printer in the normal startup mode.
 To cancel test printing, continue pressing and holding the FEED key for at least 3 sec-
onds without releasing your nger at step 7.
The buzzer emits 4 short tones, and the printer restarts.
CAUTION
Normal mode printing can also be performed when the printer is in test print mode. Note that
pressing the FEED key while the printer is in test print mode will not feed media. Instead, it will
print a test sample.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
