Citizen CL-E321 User Manual

98
——
HTTP Server
The Web monitoring function can be used to congure printer and network settings.
Refer to the pages describing the Web monitor for more information.
Refer to 6. Conguring Printer Settings Using a Browser
Port No. 80
Max. simultaneous connections 4
HTTP version HTTP/1.1
DHCP
Automatically retrieves IP address information from a DHCP server within 60 seconds
after the power is turned on.
If IP address information cannot be retrieved automatically, a xed IP address (default
is 169.254.1.10) is applied.
SNMP Agent
SNMP Version SNMPv2 (Trap function not supported)
Port No. 161
Supported MIBs HOST-RESOURCES-MIB and Citizen-MIB (Private)
Community name public
Connector Connections
Pin No. Signal Function
1 TX+ Transmit (positive)
2 TX- Transmit (negative)
3 RX+ Receive (positive)
4 N.C. -
5 N.C. -
6 RX- Receive (negative)
7 N.C. -
8 N.C. -
Compatible connectors
Printer: RJ-45 connector
LED operation
The following table describes port LED operation.
12
1. Network communication speed indicator
Communication speed LED (Green)
100 Mbps On
10 Mbps/disconnected Flashes

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
