Machine Nomenclature (control panel)
36. Machine backward switch (B)
37. Tank safety cable
38. Battery connector (red).
39. Detergent tank filler plug (**)
40. Detergent tank (**)
41. Reference table for detergent proportioning (**)
42. Detergent pump (**)
43. Detergent tank - pump connecting hose (**)
44. Detergent feed hose (**)
45. Batteries
46. Battery caps
47. Flow increase switch
48. Flow decrease switch
49. Solution flow indicator
50. Safe switch
51. Discharged battery warning light (red)
52. Semi-discharged battery warning light (yellow)
53. Charged battery warning light (green)
54. Ignition key (0 - I)
55. Detergent flow control knob (**)
36
56. Speed adjuster (B)
57. Hour meter
58.
•
Brush/pad-holder release switch(only for disc
machine)
•Extra pressure active(only for orbital machine)
59. Vacuum system switch
60.
•
Brush/pad-holder and vacuum
system
switch(only for disc machine)
•
Pad deck moving up/down and Brush/pad-
holder and vacuum system switch(only for orbital
machine)
61. Charging red LED
62. Charging yellow LED
63. Charging green LED
64. Security cover of charging jack
65. Overload protector of brush/pad
66. Overload protector of traction (B)
67. Overload protector of vacuum
(*): Optional
(**): Only for machines with Chemical Mixing
System (optional)
(A): Only for machine without traction
(B): Only for machine with traction
50 51 52 53 50
37
38
49
48
39
47
40
41
42
43
44
46
54
55
56
60 59 58 57
61 62 63
VACUUM TRACTION BRUSH
67 66 65 64
