Service Manual-CA60 04 Control System 16
Component LocationsFunction electronic board (E1) (CA60 20B/24B)
•
Signal circuit fuse 5A(F1) (CA60 20B/24B)
•
Brush actuator fuse 5A(F3) (CA60 20B/24B)
•
Battery capacity LEDs
•
LED digital display
•
Key switch
Battery Capacity LEDS
LED digital display
Key switch
Function electronic board(E1) (CA60 20B/24B)
Brush actuator fuse 5A(F3) (CA60
20B/24B)
Signal circuit fuse 5A(F1) (CA60
20B/24B)
Figure 2
Figure 3
