Service Manual-CA60 38 Squeegee System (CA60 20B/24B) 76
Maintenance and Adjustment
Squeegee Blade Changing
The two squeegee blades periodically need to be changed as they wear. The blades may be flipped or reversed to a
fresh edge up to 3 times before replacement is required. During replacement, it is important for the blades to be
installed flat without waves, and then also adjusted to rest flat against the floor.
1.
Remove the squeegee suction hose (C) from the squeegee assembly (A).
2.
Loosen the two thumbscrews (B) and slide the squeegee assembly out of the mounting slots, and remove
the squeegee.
B
C
B
A
To Next Page
