Checking/Replacing REV Motor Carbon Brushes
1. Place the motor on a workbench.
2. Remove four screws (A).
3. Remove the cover of motor(B).
4. Replace the carbon brushes.
5. Remove the screws (D) and replace the carbon brushes(C).
6. Install the cover.
7. Install the screws(A).
B
A
B
C
D
Figure 9
Figure10
Figure 11
