Service Manual-CA60 04 Control System 17
Component Locations(Continues)
Function electronic board (E1) (CA60 20D/20TD)
Signal circuit fuse 5A(F1) (CA60 20D/20TD)
Brush release fuse 20A(F3) (CA60 20D/20TD)
Brush release fuse 20A(F3) (CA60 20D/20TD)
Function electronic board (E1) (CA60 20D/20TD)
Signal circuit fuse 5A(F1) (CA60 20D/20TD)
Figure 4
