Clarke CA60 20D - Wheels and Drive Motor Disassembly;Assembly

Service Manual-CA60 14 Wheel System 28
Wheels Assembly with Drive System Motor disassembly/assembly (M3)
Disassembly
1. Drain the recovery tank.
2. Drain the clean water tank.
3. Remove the brush.
4. Remove the squeegee.
5. Remove the machine’s batteries.
6. Remove the rear panel (see the procedure in the relevant paragraph).
7. Disconnect the electrical connections (B) of the drive motor wiring from the drive system electronic
board (A).
B
A
Figure 7
