26 Tempest®2400 2-Channel Wireless Intercom System
Antenna Conguraons
When aaching the supplied ½ Wave Omnidireconal Whip antenna directly to the back of the BaseStaon, always ensure
that the antenna is rmly seated, is not cross threaded, and is located away from any metal obstrucons. Keep the antenna
away from walls or other signicant structures by at least 24 inches.
Opon 1
Install the BaseStaon in the center of the area
of communicaon, with antenna installed on
the back of the BaseStaon, having a clear
line of sight in all direcons.
Opon 2
Install the BaseStaon in a convenient
locaon and use an oponal LMR-400, a 50
ohm coax cable up to 25 to connect an
oponal direconal antenna. (15 of LMR-
400 induces about 1 dB of aenuaon.) Note:
Direconal antennas are subject to legal
restricons in some countries. Direconal
Antennas currently not available on the 900
MHz model.
Opon 3
Install the BaseStaon in an equipment rack
(1 RU) and use an oponal LMR-195, a 50
ohm coax up to 10 to mount the antenna
above the equipment rack. (5 of LMR-195
coax induces about 1 dB of aenuaon.)
