Wired Intercom Interface to the BaseStaon
Each of Tempest’s two hard wired intercom channels can interface with a 4-Wire matrix intercom or a 2-Wire party-line
intercom. Tempest supports a 4-Wire intercom interface to most major digital matrix intercom systems and other intercom
4-Wire devices. Tempest also interfaces with 2-Wire intercom systems including Clear-Com, RTS, and AudioCom (BAL)
systems, as well as compable brands. Each Tempest intercom channel can interface with one intercom system at any given
me.
While it is possible that both 2-Wire and 4-Wire systems may be connected to the same intercom channel simultaneously,
they cannot funcon at the same me, and this arrangement has the potenal to cause undesirable operaonal
complicaons, so is not recommended.
Tempest BaseStaon Wired Conguraon Controls for Connecon to Wired Intercom Systems
These controls will normally be used together to congure the Tempest BaseStaon for 2-Wire or 4-Wire operaon.
• CHAN A has been set for no wired intercom connecon – the LEDs are OFF.
• CHAN B is set for Clear-Com 2-Wire intercom connecon. The upper slide switch is in the middle posion and the
2-Wire LED aligned with CHAN B is illuminated.
Tempest BaseStaon LCD display for IN and OUT adjustment
Use the IN and OUT controls to adjust the levels on the selected channel.
In this diagram, Channel A, 2-Wire levels are selected for adjustment
2-Wire Intercom
Type Slide
Switch
Channel
Indicator
2W/4W
Indicator
Channel
Select
CH B/2W
