3
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition
1/4 windows(Optional)
1/4/9 windows
1/4/8/9 /16 windows
Monitor
Touring
Support monitor tour functions such as motion detection, and schedule
auto control.
Resolution
(PAL/NTSC
)
PAL
（
625TV Line
，
50f/s
），
NTSC
（
525TV line
，
60f/s
）
Real-time monitor
：
D1 704×576/704×480
Playback
All-channel :
D1
704×576/704×480,
HD1
352×576/352×480,
2CIF
704×288/704×240
CIF 352×288/
352×240,
QCIF
176×144/176×120
Playback
1/2-ch:
D1
704×576/704×480,
HD1
352×576/352×480,
2CIF
704×288/704×240,
CIF 352×288/
352×240,
QCIF
176×144/176×120
3-8-ch:
CIF 352×288/
352×240，
QCIF
176×144/176×120
Playback
：
All-channel：
CIF 352×288/
352×240， QCIF
176×144/176×120
Support dual streams.
Extra stream
resolution：
CIF 352×288/
352×240，
QCIF
176×144/176×120
Support dual streams.
Extra stream resolution：QCIF
176×144/176×120
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
Channel
Lock
Cover secret channel with blue screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, screen lock status, video loss status and motion
detection status are shown on the bottom left of display screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
1-ch 200-2000mV 10KΩ
（
RCA
）
Audio
Output
1-ch audio output 200-3000mv 5KΩ(RCA)
Bidirectional
Audio
Reuse the first channel audio input port to realize bidirectional talk
function.
Hard Disk
1 built-in SATA port. Support 1 HDD.
