ClimateMaster TCH072 - TCV072-240 Field Conversion of Air Discharge; Step 3 - Remove (4 x) Blower Mount Bolts; Step 4 - Rotate blower assembly 90 degrees. Reattach blower assembly to front of unit as shown. Put belt on and retighten.; Step 5 - Replace panels and misc from step1 (not shown). Reverse steps to convert straight discharge to top discharge.

THE SMART SOLUTION FOR ENERGY EFFICIENCY
Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
25
climatemaster.com
TCV072-240 Field Conversion of Air Discharge
Step 4 - Rotate blower assembly 90 degrees.
Reattach blower assembly to front of unit as
shown. Put belt on and retighten.
Step 5 - Replace panels and misc from step1
(not shown).
Reverse steps to convert straight discharge to
to
p
dischar
g
e.
Step 3 - Remove (4x) Blower Mount Bolts
