SPECIFICATIONS (CONT.)
Table 1.b.
Lodestar Electric Chain Hoists
Single Speed 230/460-3-60 or 220/380-3-50 or 220/415-3-50
Model
Load Capacity
Lifting Speed
60Hz units
Lifting Speed
50Hz units
Chain Falls
Chain Size
Chain Weight per length
of lift
Tonne kg ft/min m/min ft/min m/min in x in mm x mm lb/ft kg/m
A 1/8 125 32 9.8 26.7 8.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
AA 1/8 125 60 18.3 50.0 15.2 1 .250 x .7445 6.35 x 18.9 0.585 0.87
B 1/4 250 16 4.9 13.3 4.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
C 1/4 250 32 9.8 26.7 8.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
E 1/2 500 8 2.4 6.7 2.0 2 .250 x .7445 6.35 x 18.9 1.17 1.74
F 1/2 500 16 4.9 13.3 4.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
J 1/2 500 32 9.8 26.7 8.1 1 .312 x .8583 7.92 x 21.8 0.585 0.87
JJ 1/2 500 64 19.5 53.3 16.3 1 .312 x .8583 7.92 x 21.8 0.94 1.40
H 1 1000 8 2.4 6.7 2.0 2 .250 x .7445 6.35 x 18.9 1.17 1.74
L 1 1000 16 4.9 13.3 4.1 1 .312 x .8583 7.92 x 21.8 0.94 1.40
LL 1 1000 32 9.8 26.7 8.1 1 .312 x .8583 7.92 x 21.8 0.94 1.40
R 2 2000 8 2.4 6.7 2.0 2 .312 x .8583 7.92 x 21.8 1.88 2.80
RR 2 2000 16 4.9 13.3 4.1 2 .312 x .8583 7.92 x 21.8 1.88 2.80
RRS 2 2000 16 4.9 13.3 4.1 1 .394 x 1.18 10 x 30 1.45 2.16
RT 3 3000 5.3 1.6 4.4 1.4 3 .312 x .8583 7.92 x 21.8 2.82 4.20
RRT 3 3000 10.7 3.3 8.9 2.7 3 .312 x .8583 7.92 x 21.8 1.88 2.80
Lodestar Electric Chain Hoists
Single Speed 230/460-3-60 or 220/380-3-50 or 220/415-3-50
Model
Shortest Distance
Between Hooks
Motor Power
60Hz
Motor Power
50Hz
IP Rating
Net Weight 10’ lift less
upper suspension
in mm HP kW HP kW lb kg
A 16.9 429 0.25 0.19 0.21 0.16 54 70 31.9
AA 19.9 505 0.50 0.37 0.42 0.31 54 73 32.9
B 16.9 429 0.25 0.19 0.21 0.16 54 71 32.2
C 16.9 429 0.50 0.37 0.42 0.31 54 72 32.8
E 21.6 549 0.25 0.19 0.21 0.16 54 76 30.9
F 16.9 429 0.50 0.37 0.42 0.31 54 73 33.1
J 18.1 460 1.00 0.75 0.83 0.62 54 121 54.7
JJ 18.1 460 2.00 1.49 1.67 1.24 54 127 57.5
H 21.6 549 0.50 0.37 0.42 0.31 54 78 35.4
L 18.1 460 1.00 0.75 0.83 0.62 54 119 53.9
LL 18.1 460 2.00 1.49 1.67 1.24 54 127 57.6
R 25.8 655 1.00 0.75 0.83 0.62 54 142 64.4
RR 25.8 655 2.00 1.49 1.67 1.24 54 150 68.0
RRS 24.8 630 2.00 1.49 1.67 1.24 54 164 74.4
RT 32.1 815 1.00 0.75 0.83 0.62 54 160 72.7
RRT 32.1 815 2.00 1.49 1.67 1.24 54 173 78.4
