CM Lodestar A - Page 8

8
00001996 (REV AC) 627NH October 2014
SPECIFICATIONS (CONT.)
Table 1.c.
Lodestar Electric Chain Hoists
Two Speed 230-3-60 or 460-3-60 or 575-3-60 or 220-3-50 or 380-3-50 or 415-3-50 or 550-3-50
Model
Load Capacity
Lifting Speed
60Hz units
Lifting Speed
50Hz units
Chain Falls
Chain Size
Chain Weight per length
of lift
Tonne kg ft/min m/min ft/min m/min in x in mm x mm lb/ft kg/m
A-2 1/8 125 10.7/32 3.3/9.8 8.9/26.7 2.7/8.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
AA-2 1/8 125 20/60 6.1/18.3 16.7/50 5.1/15.2 1 .250 x .7445 6.35 x 18.9 0.585 0.87
B-2 1/4 250 5.3/16 1.6/4.9 4.4/13.3 1.4/4.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
C-2 1/4 250 10.7/32 3.3/9.8 8.9/26.7 2.7/8.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
E-2 1/2 500 2.7/8 0.8/2.4 2.2/6.7 0.7/2 2 .250 x .7445 6.35 x 18.9 1.17 1.74
F-2 1/2 500 5.3/16 1.6/4.9 4.4/13.3 1.4/4.1 1 .250 x .7445 6.35 x 18.9 0.585 0.87
J-2 1/2 500 10.7/32 3.3/9.8 8.9/26.7 2.7/8.1 1 .312 x .8583 7.92 x 21.8 0.585 0.87
JJ-2 1/2 500 21.3/64 6.5/19.5 17.8/53.3 5.4/16.3 1 .312 x .8583 7.92 x 21.8 0.94 1.40
H-2 1 1000 2.7/8 0.8/2.4 2.2/6.7 0.7/2 2 .250 x .7445 6.35 x 18.9 1.17 1.74
L-2 1 1000 5.3/16 1.6/4.9 4.4/13.3 1.4/4.1 1 .312 x .8583 7.92 x 21.8 0.94 1.40
LL-2 1 1000 10.7/32 3.3/9.8 8.9/26.7 2.7/8.1 1 .312 x .8583 7.92 x 21.8 0.94 1.40
R-2 2 2000 2.7/8 0.8/2.4 2.2/6.7 0.7/2 2 .312 x .8583 7.92 x 21.8 1.88 2.80
RR-2 2 2000 5.3/16 1.6/4.9 4.4/13.3 1.4/4.1 2 .312 x .8583 7.92 x 21.8 1.88 2.80
RT-2 3 3000 1.8/5.3 0.5/1.6 1.5/4.4 0.5/1.4 3 .312 x .8583 7.92 x 21.8 2.82 4.20
RRT-2 3 3000 3.6/10.7 1.1/3.3 3/8.9 0.9/2.7 3 .312 x .8583 7.92 x 21.8 1.88 2.80
Lodestar Electric Chain Hoists
Two Speed 230-3-60 or 460-3-60 or 575-3-60 or 220-3-50 or 380-3-50 or 415-3-50 or 550-3-50
Model
Shortest Distance
Between Hooks
Motor Power
60Hz
Motor Power
50Hz
IP Rating
Net Weight 10’ lift less
upper suspension
in mm HP kW HP kW lb kg
A-2 16.9 429 0.25 0.19 0.21 0.16 54 76 34.6
AA-2 19.9 505 0.50 0.37 0.42 0.31 54 78 35.2
B-2 16.9 429 0.25 0.19 0.21 0.16 54 77 34.9
C-2 16.9 429 0.50 0.37 0.42 0.31 54 77 35.1
E-2 21.6 549 0.25 0.19 0.21 0.16 54 82 33.6
F-2 16.9 429 0.50 0.37 0.42 0.31 54 78 35.4
J-2 18.1 460 1.00 0.75 0.83 0.62 54 133 60.2
JJ-2 18.1 460 2.00 1.49 1.67 1.24 54 135 61.1
H-2 21.6 549 0.50 0.37 0.42 0.31 54 83 37.6
L-2 18.1 460 1.00 0.75 0.83 0.62 54 131 59.4
LL-2 18.1 460 2.00 1.49 1.67 1.24 54 135 57.6
R-2 25.8 655 1.00 0.75 0.83 0.62 54 154 61.2
RR-2 25.8 655 2.00 1.49 1.67 1.24 54 158 69.8
RT-2 32.1 815 1.00 0.75 0.83 0.62 54 172 71.6
RRT-2 32.1 815 2.00 1.49 1.67 1.24 54 181 82.1
RRT 32.1 815 2.00 1.49 1.67 1.24 54 173 78.4
