COBHAM AVIATOR 700S - Equipment Drawings

98-158751-C 3-1
Chapter 3
Equipment drawings
3
This chapter has the following sections.
• SDU-5045 Compact Satellite Data Unit
• SCM-5055 SDU Configuration Module
• HPA-5015 Multi-Carrier High Power Amplifier
• DLNA Type F
• CSDU/MCHPA tray
• CSDU tray connector
• MCHPA tray connector
The following pages show copies of outline drawings of important system units relevant
for the installation.
