Electrical installation and wiring
4-18 Chapter 4: Installation 98-158751-C
4.3.16 To wire Antenna multi control
ARINC-781 compliant.
Description of the antenna multi control
Arinc 429 output to control High Gain Antenna.
Wiring diagram
See Wiring – overview on page 4-7
Pins for antenna multi control
4.3.17 To wire fault/health reporting (CFDS)
ARINC-781 compliant.
Description of the fault/health reporting
The CSDU communicates Built-In Test Equipment (BITE) reporting to the aircraft
Centralized Fault Display System (CFDS) or Central Maintenance Computer (CMC).
Wiring diagram
See Wiring – overview on page 4-7
Pins for fault/health reporting
4.3.18 To wire Ethernet 1 (AISD#1 or EFB 1)
ARINC-781 compliant.
MP09K To airborne data loader B
CSDU pin Description
CSDU pin Description
MP01E Data to HGA. A. (A429 output)
MP01F Data from HGA. B. (A429 output)
CSDU pin Description
MP08A Data from CFDS A
MP08B Data from CFDS B
MP08J Data to CFDS A
MP08K Data to CFDS B
