98-158751-C 4-1
Chapter 4
Installation
4
This chapter has the following sections:
• General installation information
• Mounting considerations
• Electrical installation and wiring
• Recommended cables
• Verifying the installation
• Activation of airtime services
4.1 General installation information
4.1.1 Overview
This chapter contains considerations and recommendations for the installation of the
AVIATOR 700S System. Interconnect harness wiring and physical mounting must satisfy
all applicable regulations. Also see the accompanying HGA Installation Manual [8] for
the antenna and also DLNA Installation Manual, which is part of the AVIATOR 700S
system.
The information, drawings and wiring diagrams in this manual are intended as a reference
for engineering planning only. The drawings and wiring diagrams contained herein do not
represent any specific STC. It is the installer’s responsibility to compose installation
drawings specific to the aircraft. This manual and the drawings and wiring diagrams
contained herein may not be used as a substitute for an STC.
4.1.2 System components
A working system consists of:
• 1 SDU-5045 CSDU
• 1 SCM-5055 SCM
• 1 HPA-5015 MCHPA
• 1 DLNA type F
• 1 HGA for more information, refer to [8]
The SCM is powered by the CSDU. The following drawing shows the minimum
installation.
Note
For optimal performance from the AVIATOR 700S system you must strictly
follow the installation guidelines in this chapter.
