SATCOM system ready for use
5-2 Chapter 5: Setup of the system 98-158751-C
Secure ORT
The Secure ORT contains all settings for the connected units, including the antenna setup,
cable losses and navigational input, interfaces to connected avionics equipment (e.g.
CMU, MCDU, audio management panels etc.). This file is locked and cannot be edited.
The Secure ORT file is generated with an ORT tool and loaded using an ARINC 429
(ARINC 615-3) or Ethernet (ARINC 615A) compliant data loader.
User ORT
The User ORT can be edited using the ORT tool (refer to ORT Tool User Guide (99-
168498) [9]), you can add a telephone directory. The User ORT file is loaded using an
ARINC 429
(ARINC 615-3)
or Ethernet (ARINC 615A) compliant data loader.
5.1.2 Uploading software
To upload software, do as follows:
1. Make sure you have access to the following files:
• Software image for each LRU, i.e. CSDU and MCHPA (typically factory loaded)
• Secure ORT (Owner Requirements Table)
• User ORT
2. Upload the files using a compliant data loader, see the data loader’s instruction
manual.
5.2 SATCOM system ready for use
Having installed the AVIATOR 700S system and loaded the necessary software, verify
that the system is fully operational.
To verify the system, refer to chapter 6, Verification.
Note
Before you start loading the software files, make sure that the SCM is connected
to the CSDU.
Note
Software upload should only be done by qualified personnel.
Note
Line of sight during operation!
Make sure that there is a line of sight between the SATCOM antenna and the
satellite in order to logon to and use the SATCOM service.
