Electrical installation and wiring
4-6 Chapter 4: Installation 98-158751-C
4.3 Electrical installation and wiring
4.3.1 Wiring symbols
Throughout the wiring section these common symbols are used:
Coax
Shield
Ground (fuselage)
Twisted
Twisted and shielded
Important
Each wiring drawing in this chapter only shows the connections referred to
in that particular section. Other connections may be required for the system
to work properly.
