HPA-5015 Multi-Carrier High Power Amplifier
98-158751-C Chapter A: Equipment specifications A-5
A.4 HPA-5015 Multi-Carrier High Power Amplifier
Characteristics Specification
Dimensions
(L x W x H)
2 MCU ARINC 600 enclosure
323.00 mm x 61.00 mm x 199.70 mm (12.72" x 2.40"
x 7.86")
Weight The maximum weight of the MCHPA is 5.0 kg (11
lbs)
Mounting Mount in an ARINC 600 2 MCU tray.
• Non-controlled-temperature location and supplied
airflow cooling, with tray integrated onto a shelf
rack system
• Non-pressurized locations.
• Pressurized locations.
Supply voltage Nominal AC supply: 115 VAC (360 - 800Hz)
Continuous operation: +90 V to 134 V
Short time operation: +70.0 V - 170 V (30ms)
Transparency time 200 ms
Typical Power Consumption AC: 240 W
Connectors Rear: ARINC 600 Attachment 11
Operating temperature
Convection airflow cooling
Forced airflow cooling
Supplied airflow cooling
-40° to +40° C (+40°C/20 hours; +55°C/30 minutes)
-40° to +70° C
-40° to +70° C
Ground survival temperature -55° to +85° C
Shelf life Max. 7 years at max. 35° C
Maximum resistance, AC input < 1.0 Ohm
Altitude For installation in non-pressurized locations: Max.
55000 ft (Cat-F2)
Decompression For installation in pressurized locations: 55000 ft
(Cat. A2)
Overpressure For installation in pressurized locations: -15000 ft
(Cat. A2)
Table A-3: MCHPA specifications
