COBHAM SAILOR 100 GX Installation Manual

List of events
D-6 Appendix D: System messages 98-141779-G
08A01-0 ADM WARNING GX Core Module
heater
There is a problem with the Core Module heater.
Check and replace if necessary.
08A02-0 ADM WARNING GX Core Module
temperature
The Core Module temperature is out of range. This
may affect performance, and the Core Module will be
shut down if the situation gets worse. If the "GX core
module heating" event is also present, the internal
heater is currently warming up the unit to its
operational temperature.
08A03-0 ADM ERROR GX Core Module
power
The Power Good signal from the Core Module is low.
The issue can either be: - Internal Core Module or
internal cable failure - Temperature of Core Module is
too high and it has been turned off (*) - GMU has
been manually switched off on the front panel (*) (*) =
Only on systems with GMU.
08A04-0 ADM WARNING iDirect modem The ACU detected a warning/error in the iDirect
modem. Log into the modem for more information.
Info:
0x00000001: Temperature error
0x00000002: Test error
0x00000004: Fan error
08A05-0 ADM WARNING GX Core Module
heating
The GX core module heater is active. It will
automatically be cleared when the core module
reaches the operational temperature level.
09000-0 KDM ERROR KDM 3V3 supply Internal 3V3 voltage supply error in the KDM.
09001-0 KDM ERROR KDM 12V supply Internal 12V voltage supply error in the KDM.
09002-0 KDM ERROR KDM display Display hardware error in the KDM.
09010-0 KDM ERROR KDM link/SW version Link to the KDM module could not be established.
Either the KDM board is malfunctioning, or - if the
system software has just been updated - the software
is too old and is not compatible with the KDM
hardware.
0A001-0 Antenna ERROR Production data Production data is invalid.
0A002-0 Antenna ERROR XIM internal Antenna configuration data stored in the PCM
module is invalid.
0A003-0 Antenna ERROR XIM external Antenna configuration data stored in the VIM module
is invalid.
0A004-0 Antenna ERROR XIM I/X match Antenna configuration data stored in the PCM
module does not match the configuration data stored
in the VIM module.
0A005-0 Antenna ERROR Antenna type The configured antenna type is not supported or
unknown.
Error code Unit Severity Description Explanation
Table D-1: List of events (Continued)
