COBHAM SAILOR 100 GX Installation Manual

List of events
98-141779-G Appendix D: System messages D-7
DDDD
System messages
0A006-0 Antenna ERROR PCM FPGA load The PCM FPGA cannot be initialised and loaded
correctly.
0A007-0 Antenna ERROR XIM FPGA load The VIM FPGA cannot be initialised and loaded
correctly.
0A008-0 Antenna ERROR XIM production Production/calibration data stored in the VIM module
is invalid.
0A00A-0 Antenna ERROR GNSS initialisation The GNSS device cannot be initialised. Check cable
and GNSS device.
0A014-0 Antenna ERROR AMB device discoveryMissing one or more of the following devices: ISM,
DDM/DMD/FDM and PMM. Check cables.
0A015-0 Antenna ERROR Azi DDM ABS device Cannot initialise the azimuth DDM/DMD/FDM. Info:
0x00000000: Device not found (possible cabling
problem) 0x0000bbaa: Device internal error
(replace device) aa=status, bb=state.
0A016-0 Antenna ERROR Xel DDM ABS device Cannot initialise the cross-elevation DDM/DMD/FDM.
Info: See 0A015-0.
0A017-0 Antenna ERROR Ele DDM ABS device Cannot initialise the elevation DDM/DMD/FDM. Info:
See 0A015-0.
0A018-0 Antenna ERROR ISM ABS device Cannot initialise the ISM Info: 0x00000000: Device
not found (possible cabling problem)
0 x 0 0 0 c b b a a : D e v i c e i n t e r n a l e r r o r ( r e p l a c e d e v i c e )
aa=status, bb=state, c=calibration data error.
0A019-0 Antenna ERROR PMM ABS device Cannot initialise the PMM. Info: See 0A015-0.
0A01A-0 Antenna ERROR BCM ABS device Cannot initialise the BCM. Info: See 0A015-0.
0A01E-0 Antenna ERROR Sensor sanity Too many invalid values measured by the ISM during
initialisation. Check for vibrations or malfunctioning
ISM.
0A021-0 Antenna ERROR Azi axis calibration Azimuth axis zero reference not found. Check belt and
zero reference module. Info:
0x00000001: Timeout (operation did not complete in
time)
0x00000010: Encoder or mechanical problem
0x00000020: Zero reference not found
0x00000040: End stop not found.
0A022-0 Antenna ERROR Xel axis calibration Cross-elevation axis zero reference or end stops not
found at expected locations. Check belt, zero
reference module, and end stops. Info: See 0A021-0.
0A023-0 Antenna ERROR Ele axis calibration Elevation axis zero reference or end stops not found
at expected locations. Check belt, zero reference
module, and end stops. Info: See 0A021-0.
Error code Unit Severity Description Explanation
Table D-1: List of events (Continued)
