D-8 Appendix D: System messages 98-141779-G
0A025-0 Antenna ERROR Antenna calibration One or more errors occurred during antenna start-up
Info:
0x00000001: Timeout (calibration did not complete
in time)
0x00000010: Azimuth axis
0x00000020: Cross-elevation axis
0x00000040: Elevation axis
0x00000080: Polarisation axis
0A028-0 Antenna ERROR Demodulator load The second receiver demodulator cannot be
initialised and loaded correctly.
0A029-0 Antenna ERROR XIM PLL lock The PLL on the VIM does not lock.
0A02B-0 Antenna ERROR ABS software version The ABS software version in the antenna is too old to
match the hardware requirements. Upload new
software via the web interface.
0A02D-0 Antenna ERROR BUC reference switch The BUC reference switches do not work. Check PCM-
VIM cable and replace cable, VIM or PCM.
0A034-0 Antenna WARNING ACU communication The communication link between ACU and antenna is
not working.
0A035-0 Antenna WARNING ISM data valid Sensor measurements from the ISM are invalid. This
indicates a malfunctioning ISM.
0A036-0 Antenna WARNING ISM data range Sensor measurements from the ISM are out of range.
0A037-0 Antenna WARNING GNSS communication Lost connection to the GNSS device.
0A038-0 Antenna WARNING GNSS data range Received information from the GNSS device which is
out of range.
0A039-0 Antenna WARNING GNSS device warning Local GNSS device warning.
0A03A-0 Antenna WARNING GNSS device error Local GNSS device error.
0A03B-0 Antenna ERROR Azi DDM shutdown The azimuth motor control has detected one of the
following situations: Extreme temperature, voltage,
current or velocity. The motor was then shut down.
This is usually a temporary situation and is probably
fixed by a restart of the system.
0A03C-0 Antenna ERROR Xel DDM shutdown As Azi DDM/DMD/FDM shutdown but detected by
the cross-elevation motor control.
0A03D-0 Antenna ERROR Ele DDM shutdown As Azi DDM/DMD/FDM shutdown but detected by
the elevation motor control.
0A03E-0 Antenna ERROR PMM shutdown As Azi DDM/DMD/FDM shutdown but detected by
the polarisation motor control.
0A03F-0 Antenna WARNING AMB timing This indicates a busy situation. It may occur during
installation procedures. No user interaction is required
unless it occurs repeatedly.
Error code Unit Severity Description Explanation
Table D-1: List of events (Continued)
