List of events
98-141779-G Appendix D: System messages D-9
DDDD
0A040-0 Antenna WARNING VIM cable attn The output power cannot be controlled correctly.
Check the Tx chain.
0A043-0 Antenna WARNING LNB voltage low The voltage for the LNB is too low probably caused by
a malfunctioning VIM or LNB.
0A044-0 Antenna WARNING LNB voltage high The voltage for the LNB is too high probably caused
by a malfunctioning VIM.
0A047-0 Antenna ERROR VIM PLL lock The PLL of the VIM is out of lock. Check the 10 MHz
reference signal.
0A048-0 Antenna WARNING VIM tuner lock The PLL of the second receiver (DVB) is out of lock.
Check the 10 MHz reference signal.
0A049-0 Antenna WARNING Azi encoder slip A slip of the azimuth encoder has been detected. If
this event is not resolved by itself after some time,
check the belt and encoder of the azimuth axis.
0A04A-0 Antenna WARNING Xel encoder slip A slip of the cross-elevation encoder has been
detected. If this event is not resolved by itself after
some time, check the belt and encoder of the cross-
elevation axis.
0A04B-0 Antenna WARNING Ele encoder slip A slip of the elevation encoder has been detected. If
this event is not resolved by itself after some time,
check the belt and encoder of the elevation axis.
0A04D-0 Antenna WARNING GNSS position No position available from the GNSS device or
position too old.
0A04E-0 Antenna WARNING GNSS velocity No velocity available from the GNSS device.
0A04F-0 Antenna WARNING Heading data Heading information is missing in the antenna.
0A050-0 Antenna ERROR Azi DDM
communication
Communication error between PCM and azimuth
DDM/DMD/FDM. Check SUB-D connectors and
cables.
0A051-0 Antenna ERROR Xel DDM
communication
Communication error between PCM and cross-
elevation DDM/DMD/FDM. Check SUB-D connectors
and cables.
0A052-0 Antenna ERROR Ele DDM
communication
Communication error between PCM and elevation
DDM/DMD/FDM. Check SUB-D connectors and cables
0A053-0 Antenna ERROR ISM communication Communication error between PCM and ISM. Check
SUB-D connectors and cables.
0A054-0 Antenna ERROR PMM communication Communication error between PCM and PMM. Check
SUB-D connectors and cables.
0A055-0 Antenna WARNING Azi DDM warning The azimuth motor controller has temporarily
observed an unusual situation for temperature,
voltage, current or velocity. No user interaction
required.
Error code Unit Severity Description Explanation
Table D-1: List of events (Continued)
