COBHAM SAILOR 100 GX Installation Manual

Configuration with the web interface
6-20 Chapter 6: Configuration 98-141779-G
•Azimuth calibration
• TX cable calibration
•BUC calibration
•Test
• Not ready (waiting for input from GNSS, e.g. GPS)
•Not ready: Initializing
• Not ready: Need pos
• Blocking zone (antenna is pointing into a blocking zone)
• No TX zone (antenna is pointing in a no TX zone; TX is off)
Sections on the Dashboard
DASHBOARD Description
GNSS position Current position of the vessel, reported by the GPS
module
Vessel heading Ship’s heading in degrees with reference to North,
provided by the ship’s gyro.
Satellite profile Name of the currently active satellite profile.
Satellite position Position of the satellite selected in Satellite profile.
RX polarisation Circular polarisation: Left-hand.
TX polarisation X-pol
RX RF frequency
a
a. Can be changed when using a generic modem profile.
Ka band receiving frequency
LNB Lo frequency 18.25 GHz (system hardware)
BUC Lo frequency 28.05 GHz (system hardware)
ACU part name, Antenna part
name, ACU serial number,
Antenna serial number,
Software version
Part names, serial numbers for ACU and ADU, software
version of the SAILOR 100 GX.
Table 6-6: Web interface, DASHBOARD, first section
MODEM
a
Description
Model Modem name, entered in SETTINGS > Modem profiles.
RX locked
status
Demodulator lock of the modem.
RX IF
frequency
Read out from the modem.
Table 6-7: Web interface, DASHBOARD, MODEM section
