CODEL GCEM4000 - Figure 16: Sensor Head Connections

Technical Manual Page 24 CODEL
OPS.080 Issue : C Rev. : Date : 16/7/08 Doc. i/d : 0080/6 Ref. : 080040
Figure 16 : Sensor Head Connections
Cable from sensor head
Cable from thermocouple
Cable from pressure transducer
Spare
