Technical Manual Page 47 CODEL
OPS.080 Issue : C Rev. : Date : 16/7/08 Doc. i/d : 0080/6 Ref. : 080040
Having now clarified the parameter to channel relationship, select the output parameter being used vpm, mg/m
3
,
mass flow, or other data (these are clearly shown at the top of the sheet). Select from the list the location
address relating to the channel to be interrogated. Normally the group marked '3 min' should be selected. This
relates to the standard data integration set into the analyser. Only use the second set if it is positively known
that the analyser has some other (factory set) integration period.
Return to the output configuration screen, input the required address to both boxes marked 'Abs. data location'
and click on 'Read'. The current configuration should now display. Change the required parameter and click on
'Apply'.
5.3.16. Read/Set RTC
Referring to the screen illustrated below set up the automatic calibration routine as follows:
