Docking station:
Fig. 5: Docking station assembly top section and underside
Main components of the docking station
No.
Description
No.
Description
(1)
Docking station
(5)
Non-slip feet
(2)
Print head wiper
(6)
Protective cap to prevent print head from drying
out
(3)
Slider to extend the print head wiper
(7)
Charging socket
(4)
Opening for the on/off switch
(8)
Battery contacts
6
7
2
3
4
5
8
4
5
1
1
