e-mark marking device Chapter 4 Initial operation
CODI Standard 1.0 Page 23 of 61
Operating and Maintenance Manual
 Is the product damage-free? Look for any deformations and cracks on the housing, cable damage,
in particular.
 Are the USB cable and connection OK?
 Are the charging cable, mains plug and charging socket OK?
The product must not go into operation if it has any visible defects or signs of damage.
Commissioning
 Remove the e-mark from the packaging.
 Remove the mains plug and separate ink cartridge packaging (print head and container with 3 ink
colors) which are under the inner base of the packaging.
 Open the e-mark cover and remove it.
Fig. 8: Opening and removing the cover
 Remove the battery from the battery compartment.
 Press the lever on top of the battery to the rear
Fig. 9: Opening the battery compartment and remove battery
 Lift the battery
 Remove the tape from the battery contacts and dispose of responsibly.
