e-mark marking device Chapter 4 Initial operation
CODI Standard 1.0 Page 24 of 61
Operating and Maintenance Manual
Fig. 10: Battery contact insulating tape
Pull down the lower flap.
- Slide the underside of the e-mark in the direction of the arrow.
- Press the panel downwards at an angle.
Fig. 11: Opening the sliding panel
Always press open the lower panel first, otherwise the ink cartridge cannot be
removed or inserted without damaging the e-mark!
Remove the ink cartridge from the packaging and dispose of the packaging responsibly.
Pull off the strip from the print head and dispose of responsibly.
