Page 12 INSTALLATION & USER'S MANUAL CLITE2
Ebox alarm relay 6.1
The searchlights electrical and mechanical condition are constantly monitored and if there is a
malfunction in the system this is indicated by icons in the panel display with clarifying warning
messages found in the panels status menu.
The control box also has a relay output that can be connected to the boat monitoring system;
see the wiring diagram for connection details.
The following errors trigger the alarm output.
Transmission issues on the CAN bus
Overcurrent protection triggered, movement blocked
Overvoltage protection triggered, voltage to searchlight motordriver/s
have exceeded its maximum value.
Undervoltage protection triggered, voltage to searchlight
motordriver/s has fallen below its minimum value.
OPWDT (message in box only)
Ethernet communication broken to all panels, see (4.1) OP WDT.
Fault auto-resets if contact is restored with at least one panel
