Colorlight CLITE2IR - 17 Technical DATA; Specifications CLITE2

INSTALLATION & USER'S MANUAL CLITE2 Page 65
TECHNICAL DATA 17.
Specifications CLITE2 17.1
MODEL RANGE
TYPE
MODEL
SOURCE
CL-2 (low) platform
CLITE 2
LED-module developed by Luminell for Colorlight
PERFORMANCE
LED LIGHT UNIT
CLITE LED module
Technology
LED
Light source
2 x 250W
Color Temp
6300 K
Color rendering index
(CRI)
70 (minimum)
Light intensity
2,4 M candela
Range
1500m (1 lux)
Beam width
5,7°
MECHANICAL
Technology
Slipring. Brushless digital controlled servo motors
Horizontal movement
Unlimited movement
Vertical movement
Unlimited movement
Speed both axis
Stepless 0-33 deg/sec
FUNCTIONS
STANDARD DIRECT
CONTROLLED
Light on/off
Dimlevel 75%, 50%, 25%
Rotation speed, stepless
STANDARD
FUNCTIONS
System activation
Parking mode
User settings
System information
Single lamp mode
STANDARD PACK 1
Position indicator
Language version
OPTIONAL PACK 2
Auto sweeping
Fixed positions
Surveillance
OPTIONAL PACK 3
Synchronized control
OPTIONAL HARDWARE
Wireless radio control
Fiber optic control cable
Thermal camera unit (not for retrofitting)
Customized color
Daylight camera unit (not for retrofitting)
Wet paint (AWL grip or similar)
Extra remote panel (s)
External power supply for panel (s)
Ethernet switch, 5 port and 8 port
Upside-down installation
TECHNICAL DATA
Power
consumption
650W (max load) (EBOX 24VDC)
850W (max load) EBOX 100-240VAC)
Heat load
-
LED-module
size
305x180 mm (x2)
LED life
Up to 100 000 hours
Ballast
No external ballast
Signal cable
4x2x1 shielded, twisted pair
Power cable
5G4 shielded
OP3G cable
Ethernet CAT5-FTP Fiber available for long distance
Serial cable
RS485/RS232 Optional. ICD for external control
available
SEARCHLIGHT BODY
EBOX DC
EBOX AC
OPERATOR PANEL
Weight (kg)
28
6
11
0,5
Static size (cm)
26x57x50 cm *
30x25x15 cm *
30x34x15 cm *
13x9x6 cm *
Material
Acid proof stainless steel 1.4401.
Led module in seawater resistant
powder coated aluminium.
Coated steel
Coated steel
Anodized aluminum / ABS
Paint
Powder coat white RAL 9016
Powder coat grey RAL 7035
Powder coat grey RAL 7035
Anodized black
IP-Class
IP66
IP22
IP22
IP56
Operating temp
range
-40º / +55º Celsius
+5º / +45º Celsius
+5º / +45º Celsius
-20º / +55º Celsius
Input power
Powered from ebox
24VDC
100-240VAC 50-60Hz
9-28 VDC (max 200 mA @ 24V)
* see drawings for detailed info
