INSTALLATION & USER'S MANUAL CLITE2 Page 13
INSTALLATION 7.
Lifting the searchlight 7.1
The picture on the right shows
how to place the lifting slings
when there is no lift loop
available.
Also in this case the searchlight
cables must be secured to the
hook to avoid straining and
damage on the cable glands.
Preferable lift the searchlight by
the temporary lift loop on top of
the center house. After safely
fixed the searchlight, remove the
lift loop.
During the lift, the searchlight
cables must be secured to the
hook to avoid straining and
damage on the cable glands.
