ComAp IM-NT - Page 104

InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
104
12.2.1.4 Setpoint: #SysPFCtrl PtM
Group
Process Control
Range [units]
BASEPF, VSHARING [-]
Related FW
3.0
Description
In BTB application many load control and power management functions does
not play active role!
This setpoint is used to adjust the power factor control type in parallel-to-
mains operation.
BASEPF
The gen-sets are controlled by their power factor control
loops (i.e. as in SPtM) to provide constant power factor
adjusted by the setpoint #SysPwrFactor. The InteliMains
does not play active role regarding power factor control in
parallel-to-mains operation.
VSHARING
The gen-sets are controlled by the InteliMains through the
VAr sharing line (CAN2 bus). The InteliMains power factor
control mode is selected by the setpoint PF ctrl PtM.
NOTE:
This type of power factor control is used for import/export
mode only.
NOTE:
If the power factor control mode is switched to VSHARING the load control
type must be switched to LDSHARING and the equivalent load control mode
must be used.
NOTE:
# sign in the name of this setpoint marks that this setpoint is shared among
all controllers connected by CAN2 bus.
12.2.1.5 Setpoint: I/E-PbL meas
Group
Process Control
Range [units]
NONE, CT INPUTS, ANALOG INPUT [-]
