InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
15.2.1.64 Binary output: PeriphCommErr
The output is closed while there is an error in the communication with any
peripheral unit (e.g. IS-AIN8, IGS-PTM, ...).
15.2.1.65 Binary output: WrongPhSeq
Binary output WrongPhSeq is active when at least one of the following
conditions is fulfilled: BusL/BusR phase is inverted or wrong BusL/BusR
phase sequence or opposed BusL/BusR phase sequence is detected.
15.2.1.66 Binary output: User Button 1
This output can be specified for example on buttons on IV-5/8 or in SCADA
diagram in InteliMonitor. Its state depends on function assigned to the related
button.
It is possible to lock UserButton commands in configuration to specific user
level. Buttons 1-8 and 9-16 are locked separately.
Pressing the button changes the state of log. binary output
User Button X to closed. When the output is closed and the
button is pressed state is not changed.
Pressing the button changes the state of log. binary output
User Button X to opened. When the output is opened and
the button is pressed state is not changed.
Pressing the button changes the state of log. binary output
User Button X to opened or closed depending on previous
state (it is changed to the opposite state).
Pressing the button issues log. binary output User Button X
to close for one second.
NOTE:
Repeated pressing of button during the closed period (one
second) causes issuing another puls of length of one
second to be generated from the moment of button
pushing.
