ComAp InteliDrive Lite Global Guide

ID-FLX Lite & Telecom Global Guide
117
Setpoint group Engine parameters Related FW 2.5.0
Range [units] 0 .. 240 [s]
Default value 60 -
Step 1
Comm object 9815 Related applications
Description
Under normal conditions the engine must certainly stop within this period. The period starts by issuing stop
command.
Note: Stop of engine is detected when all following conditions are met: RPM <2, Oil pressure <
StartingPOil and D+ input isn’t active.
Stop fail is detected if there is difference between those conditions.
Note: In case when stop time period is lower than "stop engine detected" + 10s, stop time period is
extended to this value due to safety reason. (stop engine detected = RPM<2, OilP not detected, D+ not
active)
Stop time
6 back to List of setpoints
Setpoint group Engine parameters Related FW 2.5.0
Range [units] DIESEL, GAS [-]
Default value -
Step -
Comm object 9100 Related applications
Description
Setpoint setting determines behavior of the Binary output FUEL SOLENOID.
DIESEL
Output closes 1 sec before Binary output STARTER.
The output opens if Emergency stop comes or Cooled engine is stopped and in
pause between repeated starts.
GAS
In this mode of operation the output closes to open the gas valve and enable the
engine to start. The delay of Fuel solenoid output activation in relation to Starter
output is defined by FuelSol offset. The output closes only if RPM > 30 (i.e. the
starter motor is engaged).
The output opens if there is any reason to stop the engine or in pause between
repeated starts.
Note: In the case of gas engine, the underspeed protection cannot be blocked by the Sprinkler function.
For gas engines, it is strongly recommended to use the pick-up sensor, as non-zero RPM detection is
required during the start procedure.
Fuel solenoid
6 back to List of setpoints
