9.2.5 IL-NT GPRS (optional card)
Plug-in into ID-Lite controller COMMUNICATION MODULE port.
Quad Band 850 / 900 / 1800 / 1900 MHz
GPRS multi-slot class 10
CSD communication up to 14.4 kbps
TCP/IP communication over GPRS
Voltage supply 8-36 V DC
9.2.6 IL-NT AOUT8 (optional card)
Plug-in into ID-Lite controller EXTENSION MODULE port.
Number of PWM outputs 8
PWM frequency 1200 Hz
Maximum current 0.5 A
Maximum switching voltage 36 V DC
Output resistance 1 Ω
Resolution 10 bits
9.2.7 IL-NT AIO (optional card)
Plug-in into ID-Lite controller EXTENSION MODULE port.
Resolution 10 bits
Number of Analog inputs 4 (2400 Ω, 20 mA, 4 V)
Maximal resistance range 2400 Ω
Maximal voltage range 4 V
Current range 0-20 mA
Input impedance (current) 180 Ω for mA measuring
Input impedance (voltage) ˃68 kΩ for V measuring
Resistance measurement tolerance ±2 % ±2 Ω
Voltage measurement tolerance ±1 % ±1 mV
Current measurement tolerance ±2 % ±0.2 mA
Number of Analog outputs
1 (21 mA, max.load 100 Ω; 4.6 V, max.10 mA;
PWM 500 Hz (5 V / 10 mA)
Voltage measurement tolerance ±1.5 % ±10 mV
Current measurement tolerance ±2 % ±0.1 mA
