InteliLite Global Guide
198
Subgroup: Voltage Protection
Setpoint group Generator settings Related FW 1.2.1
Range [units]
Generator > Voltage Wrn (page 198) .. 200 [%]
Default value 110 % Alternative config NO
Step
1 % of Nominal Voltage Ph-N (page 158) or Nominal Voltage Ph-Ph (page 159)
Comm object 8291 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator overvoltage protection. All three phases are checked. Maximum out of three is used.
Note: Overvoltage protection is evaluated according to setting of setpoint Connection type (page 157).
3Ph4Wire and 3Ph3Wire connections are evaluated according to Ph-Ph nominal voltage (Nominal
Voltage Ph-Ph (page 159)) and Split Phase and Mono Phase connections are evaluated according to Ph-
N nominal voltage (Nominal Voltage Ph-N (page 158)).
Generator > Voltage Sd
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.2.1
Range [units]
Generator < Voltage Wrn (page 199) .. Generator > Voltage Sd (page 198) [%]
Default value 110 % Alternative config NO
Step
1 % of Nominal Voltage Ph-N (page 158) or Nominal Voltage Ph-Ph (page 159)
Comm object 9686 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator overvoltage protection. All three phases are checked. Maximum out of three is used.
Note: Overvoltage protection is evaluated according to setting of setpoint Connection type (page 157).
3Ph4Wire and 3Ph3Wire connections are evaluated according to Ph-Ph nominal voltage (Nominal
Voltage Ph-Ph (page 159)) and Split Phase and Mono Phase connections are evaluated according to Ph-
N nominal voltage (Nominal Voltage Ph-N (page 158)).
Generator > Voltage Wrn
6 back to List of setpoints
