InteliLite Global Guide

199

Setpoint group Generator settings Related FW 1.2.1

Range [units]

0 .. Generator < Voltage Wrn (page 199) [%]

Default value 70 % Alternative config NO

Step

1 % of Nominal Voltage Ph-N (page 158) or Nominal Voltage Ph-Ph (page 159)

Comm object 8293 Related applications AMF, MRS

Config level Standard

Setpoint visibility Always

Description

Threshold for generator undervoltage protection. All three phases are checked. Minimum out of three is used.

Note: Overvoltage protection is evaluated according to setting of setpoint Connection type (page 157).

3Ph4Wire and 3Ph3Wire connections are evaluated according to Ph-Ph nominal voltage (Nominal

Voltage Ph-Ph (page 159)) and Split Phase and Mono Phase connections are evaluated according to Ph-

N nominal voltage (Nominal Voltage Ph-N (page 158)).

Note: When there is no control of breakers, the type of protection is Sd not BOC.

Generator < Voltage BOC
