InteliLite Global Guide
200
Setpoint group Generator settings Related FW 1.2.1
Range [units] 0,0 .. 600,0 [s]
Default value 3,0 s Alternative config NO
Step 0,1 s
Comm object 9103 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Delay for Generator > Voltage Sd (page 198), Generator > Voltage Wrn (page 198), Generator < Voltage BOC
(page 199) and Generator < Voltage Wrn (page 199) protection.
Generator <> Voltage Delay
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.2.1
Range [units]
1 .. 200 [%] of Nominal Voltage Ph-Ph (page 159)
Default value 10 % Alternative config NO
Step
1 % of Nominal Voltage Ph-Ph (page 159)
Comm object 8288 Related applications AMF, MRS
Config level Advanced
Setpoint visibility
Conditioned by the setpoint Connection type (page 157)
Description
Threshold for generator voltage unbalance alarm.
Note: When there is no control of breakers, the type of protection is Sd not BOC.
Voltage Unbalance BOC
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.2.1
Range [units] 0,0 .. 600,0 [s]
Default value 3,0 s Alternative config NO
Step 0,1 s
Comm object 8289 Related applications AMF, MRS
Config level Advanced
Setpoint visibility
Conditioned by the setpoint Connection type (page 157)
Description
Delay for Voltage Unbalance BOC (page 200) protection.
Voltage Unbalance BOC Delay
6 back to List of setpoints
