ComAp InteliLite MRS16 User Manual

InteliLite Global Guide
87
Events
specification
Protection
type
Description
Analog Input 2 Sd SD
Value measured on analog input 2 is </> than Analog Protection 2 Sd
(page 206) setpoint.
Analog Input 3 Wrn WRN
Value measured on analog input 3 is </> than Analog Protection 3
Wrn (page 208) setpoint.
Analog Input 3 Sd SD
Value measured on analog input 3 is </> than Analog Protection 3 Sd
(page 209) setpoint.
Analog Input 4 Wrn WRN
Value measured on analog input 4 is </> than Analog Protection 4
Wrn (page 211) setpoint.
Analog Input 4 Sd SD
Value measured on analog input 4 is </> than Analog Protection 4 Sd
(page 212) setpoint.
Wrn Battery Voltage WRN
Battery voltage is out of limits given by Battery < Voltage (page 190)
and Battery > Voltage (page 190) setpoints.
Binary input Configurable Warning/BOC/Shutdown alarms on the binary inputs.
Sd Battery Flat SD
If the controller switches off during starting sequence (STARTER
(PAGE 510) output is active) it doesn’t try to start again and activates
this protection (controller assumes bad battery condition).
Sd Start Fail SD Gen-set start failed. All crank attempts were tried without success.
Parameters Fail NONE
Wrong check-sum of parameters. Happens typically after
downloading new firmware or changing of the parameter. The
controller stays in INIT mode. Check all parameters, change value of
at least one parameter.
Sd Gen Lx >V
BOC Gen Lx <V
(where x=1,2,3)
SD
BOC
The generator voltage is out of limits given by Gen <V BOC and Gen
>V Sd setpoints.
BOC Gen V
Unbalance
BOC
The generator voltage is unbalanced more than the value of Voltage
Unbalance BOC (page 200) setpoint.
BOC Gen >,
<Frequency
BOC
The generator frequency is out of limits given by Generator >
Frequency BOC (page 201) and Generator < Frequency BOC (page 201)
setpoints.
BOC Current
Unbalance
BOC
The generator current is unbalanced more than the value of Current
Unbalance BOC (page 197) setpoint.
BOC Current IDMT BOC
Generator current exceeds the limit for IDMT protection given by
Nominal Current (page 156) and IDMT Overcurrent Delay (page 196)
setpoints.
BOC Overload BOC
The load is greater than the value given by Overload BOC (page 194)
setpoint.
Sd Earth Fault SD
This alarm is activated when Earth Fault value exceeds Earth Fault
Sd (page 340) limit for at least Earth Fault Delay (page 339) period.
Sd Overspeed SD
The protection comes active if the speed is greater than Overspeed Sd
(page 175) setpoint.
