InteliMains 210 Global Guide
121
List of available PLC blocks
PLC block Number of blocks
OR/AND 16
XOR/RS 2
Comparator with hysteresis (Comp Hyst) 2
Comparator with delay (Comp Time) 2
Timer 1
Delay 2
Force history record (Force Hist) 2
Force protection (Force Prot) 2
Working with the editor
If the currently opened archive does not contain any PLC program, then an empty drawing is created
automatically when you select the PLC Editor. The procedure of creation of a PLC drawing (program) contains
following essential steps:
Adjust the sheet to your needs. See Working with sheets (page 121) for more information.
Add PLC blocks into the sheets. See Adding PLC blocks (page 122) for more information.
Define inputs and outputs of the PLC program. See Define inputs and outputs (page 123) for more
information.
Create connections between inputs, blocks and outputs. See Creating wires (page 125) for more
information.
Adjust properties of the blocks. See for more information about blocks.
Working with sheets
Drag the sheet edges to re-size the sheet according to your needs.
