Setpoint group Scheduler Related FW 2.0.0
Range [units] Disable / No Func / TEST / Test OnLd / MFail Blk / Mode OFF [-]
Default value No Func Alternative config NO
Step [-]
Comm object 15359 Related applications MCB, MGCB, BTB
Description
It is possible to choose from following Timer functions. Binary output EXERCISE TIMER 2 (PAGE 458) is
always activated when Timer is active regardless of chosen timer function. Timer functions require controller
running in AUTO mode.
IMPORTANT: Binary output is activated always when timer should be activated e.g. even
when controller is in different mode than AUTO.
Timer 1 has the highest priority. Timer 8 has the lowest priority. So if Timer 1 is configured for OFF mode and
Timer 8 is over the same time configured for AUTO mode, controller will work in OFF mode.
Controller activates timer whenever it is powered up even in period, where timer should be already running.
Disable The Timer is disabled.
No Func There is no any other function, only binary output of timer is activated.
TEST When this option is chosen then the binary output of timer is internally connected to the
binary input Remote TEST.
TEST OnLd When this option is chosen then the binary output of timer is internally connected to the
Remote TEST On Load binary input.
MFail Blk When this option is chosen then the binary output of timer is internally connected to the
Mains Fail Block binary input.
Mode OFF When this option is chosen then the binary output of timer is internally connected to the
Remote OFF binary input.
Timer 2 Function
6 back to List of setpoints
Setpoint group Scheduler Related FW 2.0.0
Range [units] Off / Once / Repeated [-]
Default value Off Alternative config NO
Step [-]
Comm object 0 Related applications MCB, MGCB, BTB
Description
Defines repetition of Timer 2 Function (page 257).
Off
Timer 2 Function (page 257) will not be activated.
Once
Timer 2 Function (page 257) will be activated only one time.
Repeated
Timer 2 Function (page 257) will be repeatedly activated.
Timer 2 Repetition
6 List of setpoints (page 165)
